Product EN0670-1
- Description
- Brake disc
- Axe
- Front
- No. of Pieces
- 1
- Url
- https://catalogo.energitbrakes.com/Producto/Details?idProducto=EN0670-1
- Weight (gr.)
- 7164
- R90 Homologation
-
90R-02C0415/0093
- Measures
- Ø280x16x78.6
-
Brake Disc Type:
solid -
Minimum thickness [mm]:
14.4 -
Hole Arrangement/Number:
5 -
Bolt Hole Circle Ø [mm]:
112 -
Wheel Hub Diameter [mm]:
88
| Brand | OE Reference |
|---|---|
| MERCEDES-BENZ | 601 420 00 72 |
| MERCEDES-BENZ | 601 420 02 72 |
| MERCEDES-BENZ | 601 420 50 12 |
| MERCEDES-BENZ | 601 421 50 12 |
| MERCEDES-BENZ | 601 421 51 12 |
| Maker | Cross reference |
|---|---|
| ATE | 24.0116-0100.1 |
| BENDIX BRAKING-TMD | BDS1949 |
| BOSCH | 0 986 478 201 |
| BREMBO | 08.3959.20 |
| LETEC | LBM040S |
| ROAD HOUSE | 6291.00 |
| TRW | DF1577 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 310 2.3 (602.011, 602.022, 602.021, 602.012) |
M 102.942 |
1 | 01/1982-12/1994 | 2299 | 70 | 95 | 2 |
| 307 D 2.4 |
OM 616.937 OM 616.939 |
2 | 06/1982-01/1990 | 2399 | 53 | 72 | 2 |
| 307 D 2.4 (602.323, 602.321) |
OM 616.937 |
2 | 04/1977-01/1983 | 2399 | 48 | 65 | 2 |
| 308 D 2.3 (602.311, 602.323, 602.322, 602.321) |
OM 601.940 |
2 | 06/1989-02/1996 | 2299 | 60 | 82 | 2 |
| 308 D 2.3 (602.313) |
OM 601.940 |
2 | 06/1989-02/1996 | 2299 | 58 | 79 | 2 |
| 309 D 3.0 (602.411, 602.423, 602.413, 602.412) |
OM 617.913 |
2 | 10/1982-01/1990 | 2998 | 65 | 88 | 2 |
| 310 D 2.9 (602.413, 602.417, 602.416) |
OM 602.940 |
2 | 06/1989-02/1996 | 2874 | 70 | 95 | 2 |
| 310 D 2.9 (602.417) |
OM 602.940 |
2 | 06/1989-02/1996 | 2874 | 72 | 98 | 2 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 210 2.3 (601.011, 601.067, 601.066, 601.012) |
M 102.942 |
1 | 04/1977-10/1989 | 2298 | 70 | 95 | 2 |
| 210 2.3 (601.011, 601.067, 601.066, 601.012) |
M 115.955 |
1 | 04/1977-10/1989 | 2307 | 63 | 86 | 2 |
| 207 D 2.4 |
OM 616.937 |
2 | 12/1977-10/1989 | 2399 | 53 | 72 | 2 |
| 207 D 2.4 (601.311, 601.322, 601.321, 601.312) |
OM 616.917 |
2 | 04/1977-12/1982 | 2404 | 48 | 65 | 2 |
| 208 D 2.3 (601.311, 601.312, 601.316, 601.317, 601.328,... |
OM 601.940 |
2 | 11/1988-02/1996 | 2299 | 58 | 79 | 2 |
| 208 D 2.3 (601.321) |
OM 601.940 |
2 | 06/1989-02/1996 | 2299 | 60 | 82 | 2 |
| 209 D 2.9 (601.411, 601.412, 601.416, 601.417, 601.428,... |
OM 617.913 |
2 | 12/1982-01/1990 | 2998 | 65 | 88 | 2 |
| 210 D 2.8 (601.422) |
OM 602.940 |
2 | 11/1988-02/1996 | 2874 | 72 | 98 | 2 |
| 210 D 2.9 (601.411, 601.412, 601.416, 601.417, 601.428,... |
OM 602.940 |
2 | 11/1988-02/1996 | 2874 | 70 | 95 | 2 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 308 D 2.3 (602.373, 602.371) |
OM 601.940 |
2 | 06/1989-02/1996 | 2299 | 60 | 82 | 2 |
| 308 D 2.3 (602.373) |
OM 601.940 |
2 | 05/1990-02/1996 | 2299 | 58 | 79 | 2 |
| 310 D 2.9 (602.477, 602.476) |
OM 602.940 |
2 | 06/1989-02/1996 | 2874 | 70 | 95 | 2 |
| 310 D 2.9 (602.477) |
OM 602.940 |
2 | 06/1990-02/1996 | 2874 | 72 | 98 | 2 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 210 2.3 |
M 115.955 |
1 | 05/1977-12/1982 | 2307 | 63 | 86 | 2 |
| 210 2.3 (601.011, 601.067, 601.066, 601.012) |
M 102.945 |
1 | 05/1989-02/1996 | 2298 | 77 | 105 | 2 |
| 210 2.3 (601.061, 601.067, 601.066, 601.062) |
M 102.942 M 102.946 |
1 | 07/1982-02/1996 | 2298 | 70 | 95 | 2 |
| 207 D 2.4 (601.361, 601.367, 601.366, 601.362) |
OM 616.937 OM 616.939 |
2 | 06/1982-01/1990 | 2399 | 53 | 72 | 2 |
| 208 D 2.3 (601.362, 601.361) |
OM 601.940 |
2 | 11/1988-02/1996 | 2299 | 58 | 79 | 2 |
| 208 D 2.3 (601.362) |
OM 601.940 |
2 | 10/1988-02/1996 | 2299 | 60 | 82 | 2 |
| 209 D 2.9 (601.461, 601.467, 601.466, 601.462) |
OM 617.913 |
2 | 12/1982-01/1990 | 2998 | 65 | 88 | 2 |
| 210 D 2.8 (601.461, 601.467, 601.466, 601.462) |
OM 602.940 |
2 | 10/1988-02/1996 | 2874 | 70 | 95 | 2 |
| 210 D 2.8 (601.466) |
OM 602.940 |
2 | 10/1988-02/1996 | 2874 | 72 | 98 | 2 |
| 407 D 2.4 (611.367, 611.368) |
OM 616.937 |
2 | 04/1981-07/1982 | 2399 | 53 | 72 | 2 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 208 2.3 |
M 115.955 M 115.972 |
1 | 05/1977-12/1982 | 2307 | 63 | 86 | 2 |
| 210 2.3 (601.066, 601.077, 601.076, 601.067) |
M 102.942 |
1 | 07/1982-01/1990 | 2298 | 70 | 95 | 2 |
| 210 2.3 (601.066, 601.077, 601.076, 601.067) |
M 102.945 |
1 | 05/1989-02/1996 | 2298 | 77 | 105 | 2 |
| 207 D 2.4 (601.371, 601.376, 601.377) |
OM 616.937 OM 616.939 |
2 | 07/1982-01/1990 | 2399 | 53 | 72 | 2 |
| 207 D 2.4 (601.371, 601.376, 601.377) |
OM 616.917 OM 616.934 |
2 | 05/1977-12/1982 | 2404 | 48 | 65 | 2 |
| 208 D 2.3 (601.371, 601.372, 601.376, 601.377) |
OM 601.940 |
2 | 10/1988-02/1996 | 2299 | 58 | 79 | 2 |
| 208 D 2.3 (601.377) |
OM 601.940 |
2 | 10/1988-02/1996 | 2299 | 60 | 82 | 2 |
| 209 D 2.9 (601.477, 601.476) |
OM 617.913 |
2 | 12/1982-01/1990 | 2998 | 65 | 88 | 2 |
| 210 D 2.8 (601.477, 601.476) |
OM 602.940 |
2 | 11/1988-02/1996 | 2874 | 70 | 95 | 2 |
| 210 D 2.8 (601.477) |
OM 602.940 |
2 | 11/1988-02/1996 | 2874 | 72 | 98 | 2 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 310 2.3 (602.062, 602.061) |
M 102.942 |
1 | 06/1989-02/1996 | 2298 | 70 | 95 | 2 |
| 310 2.3 (602.062, 602.061) |
M 102.945 |
1 | 01/1989-12/1995 | 2299 | 77 | 105 | 2 |
| 307 D 2.4 |
OM 616.937 OM 616.939 |
2 | 10/1982-01/1990 | 2399 | 53 | 72 | 2 |
| 308 D 2.3 (602.361, 602.362, 602.373, 602.372, 602.363) |
OM 601.940 |
2 | 06/1989-02/1996 | 2299 | 60 | 82 | 2 |
| 308 D 2.3 (602.368) |
OM 601.940 |
2 | 11/1988-02/1996 | 2299 | 58 | 79 | 2 |
| 309 D 3.0 (602.461, 602.462, 602.477, 602.476, 602.463) |
OM 617.913 |
2 | 10/1982-01/1990 | 2998 | 65 | 88 | 2 |
| 310 D 2.9 (602.466, 602.477, 602.476, 602.467) |
OM 602.940 |
2 | 06/1989-02/1996 | 2874 | 70 | 95 | 2 |
| 310 D 2.9 (602.467) |
OM 602.940 |
2 | 06/1989-02/1996 | 2874 | 72 | 98 | 2 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 410 (611.017, 611.018) |
M 102.942 |
1 | 08/1982-06/1995 | 2298 | 70 | 95 | 2 |
| 410 (611.017, 611.018) |
M 102.945 |
1 | 08/1982-06/1995 | 2298 | 77 | 105 | 2 |
| 407 D (611.317, 611.318) |
OM 616.913 OM 616.939 |
2 | 07/1981-01/1989 | 2398 | 53 | 72 | 2 |
| 408 D (611.317, 611.318) |
OM 601.940 |
2 | 11/1988-06/1995 | 2299 | 58 | 79 | 2 |
| 408 D (611.317, 611.318) |
OM 601.940 |
2 | 11/1988-06/1995 | 2299 | 60 | 82 | 2 |
| 409 D (611.417, 611.418) |
OM 617.913 |
2 | 04/1982-01/1989 | 2998 | 65 | 88 | 2 |
| 410 D (611.417, 611.418) |
OM 602.940 |
2 | 11/1988-06/1995 | 2874 | 70 | 95 | 2 |
| 410 D (611.417, 611.418) |
OM 602.940 |
2 | 11/1988-06/1995 | 2874 | 72 | 98 | 2 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 410 (611.067, 611.068) |
M 102.942 |
1 | 08/1982-06/1995 | 2298 | 70 | 95 | 2 |
| 410 (611.067, 611.068) |
M 102.945 |
1 | 08/1982-06/1995 | 2298 | 77 | 105 | 2 |
| 407 D (611.367, 611.368) |
OM 616.913 OM 616.939 |
2 | 07/1981-01/1989 | 2398 | 53 | 72 | 2 |
| 408 D (611.367, 611.368) |
OM 601.940 |
2 | 11/1988-06/1995 | 2299 | 58 | 79 | 2 |
| 408 D (611.367, 611.368) |
OM 601.940 |
2 | 11/1988-06/1995 | 2299 | 60 | 82 | 2 |
| 409 D (611.467, 611.468) |
OM 617.913 |
2 | 04/1982-01/1989 | 2998 | 65 | 88 | 2 |
| 410 D (611.467, 611.468) |
OM 602.940 |
2 | 11/1988-06/1995 | 2874 | 70 | 95 | 2 |
| 410 D (611.467, 611.468) |
OM 602.940 |
2 | 11/1988-06/1995 | 2874 | 72 | 98 | 2 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| L 408 G (309.012, 309.013, 309.014, 309.015, 309.016,... |
M 115.928 |
1 | 08/1972-12/1974 | 2197 | 55 | 75 | 2 |
| L 408 G (309.012, 309.013, 309.014, 309.015, 309.016,... |
M 115.921 |
1 | 08/1972-12/1974 | 2197 | 63 | 85 | 2 |
| L 409 (309.011, 309.012, 309.013, 309.014, 309.015,... |
M 115.952 |
1 | 01/1975-08/1982 | 2307 | 66 | 90 | 2 |
| L 410 (309.011, 309.012, 309.013, 309.014, 309.015,... |
M 102.943 |
1 | 08/1982-12/1988 | 2299 | 70 | 95 | 2 |
| L 405 D |
OM 615 |
2 | 01/1972-12/1980 | 2197 | 44 | 60 | 2 |
| L 406 DG (309.111, 309.112, 309.113, 309.114, 309.115,... |
OM 615.910 |
2 | 01/1968-12/1974 | 2197 | 44 | 60 | 2 |
| L 407 D (309.111, 309.112, 309.113, 309.114, 309.115,... |
OM 616.910 |
2 | 01/1975-12/1988 | 2404 | 48 | 65 | 2 |
| L 407 D (309.111, 309.112, 309.113, 309.114, 309.115,... |
OM 616.910 |
2 | 01/1975-12/1988 | 2404 | 53 | 72 | 2 |
| L 508 DG (309.411, 309.412, 309.413, 309.414, 309.415,... |
OM 314.946 OM 314.948 |
2 | 01/1970-12/1988 | 3782 | 63 | 85 | 2 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| L 408 G (309.000, 309.001, 309.002, 309.003, 309.011,... |
M 115.928 |
1 | 08/1972-12/1974 | 2197 | 55 | 75 | 2 |
| L 408 G (309.000, 309.001, 309.002, 309.003, 309.011,... |
M 115.921 |
1 | 08/1972-12/1974 | 2197 | 63 | 85 | 2 |
| L 409 (309.000, 309.001, 309.002, 309.003) |
M 115.952 |
1 | 01/1975-08/1982 | 2307 | 66 | 90 | 2 |
| L 410 (309.000, 309.002) |
M 102.943 |
1 | 08/1982-12/1988 | 2299 | 70 | 95 | 2 |
| L 405 D |
OM 615 |
2 | 01/1972-12/1980 | 2197 | 44 | 60 | 2 |
| L 406 DG (309.100, 309.101, 309.102, 309.103) |
OM 615.910 |
2 | 01/1968-12/1974 | 2197 | 44 | 60 | 2 |
| L 407 D (309.100, 309.101, 309.102, 309.103) |
OM 616.910 OM 616.917 |
2 | 01/1975-12/1988 | 2404 | 48 | 65 | 2 |
| L 407 D (309.100, 309.101, 309.102, 309.103) |
OM 616.910 |
2 | 01/1975-12/1988 | 2404 | 53 | 72 | 2 |
| L 508 DG (309.400, 309.401, 309.402, 309.403, 309.404,... |
OM 314.946 OM 314.948 |
2 | 01/1970-12/1988 | 3782 | 63 | 85 | 2 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 507 D (667.361, 667.362) |
OM 616.914 |
2 | 04/1986-04/1989 | 2399 | 53 | 72 | 2 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 507 D (667.301, 667.302, 667.341, 667.342) |
OM 616.914 |
2 | 04/1986-04/1989 | 2399 | 53 | 72 | 2 |
| 507 DK (667.341, 667.342) |
OM 616.914 |
2 | 04/1986-04/1989 | 2399 | 53 | 72 | 2 |
